Outdoor Microphone

Nor1217

Outdoor microphone protection

The Nor1217 outdoor microphone protection is the semi‑permanent version of the Nor1216 outdoor microphone, designed for professional environmental noise monitoring. It offers the same robust all‑weather protection and SysCheck functionality, ensuring reliable performance and easy functional verification in the field.

Nor1217 is optimised for use with the standard preamplifier and microphone supplied with the Nor140, Nor145, and Nor150 sound analyzers, making it straightforward to integrate into existing Norsonic measurement setups.

Together with these instruments, the Nor1217 provides a practical and cost‑efficient solution for outdoor noise measurements in applications such as environmental noise compliance, long‑term monitoring, and industrial noise assessments.

Get a quote

Features

Specifications

Accessories

Downloads

Features

Outdoor microphone for community and aircraft noise.
Fulfils IEC 60651, IEC 61672 class 1 and ANSI S1.4 type 1 (when used with Nor140, Nor145 and Nor150 sound level meters).
Protection class IP 55 (dust and water).
Easy to calibrate with a normal ½” sound calibrator.
Microphone verification by SysCheck facility.
Low self-noise – typically below 17 dB, A-weighted.
Directly powered and supported by Nor140 and Nor150 (built in selectable frequency correction networks and SysCheck signal generator).
Low cost. Use microphone and preamplifier supplied with Nor140, Nor145 and Nor150.
Supplied with individual calibration certificate.
Approved by PTB, Germany.

Specifications

Acoustic performance: IEC 60651, IEC 61672 class 1 and ANSI S1.4 type 1 (frequency correction applied) with a suitable instrumentMax Sound pressure level: >140 dB peak dependent on supply voltage.

Microphone cartridge: Nor1227 or Nor1225 (1/2” 50 mV/Pa)

Polarization voltage: 0 volt (Nor1227) 200V (Nor1225)

Inherent noise: < 17 dB A-weighted

Reference direction: Vertical or horizontaldependent on the applied frequency correction

Ingress Protection Category: IP55 according to IEC 60529.

Supply voltage: ±14 volt to ±60 volt

Current consumption: 1,5mA

Connector: 7 pin Lemo type 1B male

Temperature range: -40ºC to +85ºC

Height: 395 mm / 15.5”(without tripod adapter)

Diameter: Approx 80 mm / 3.1” (with windshield)

Weight: Approx 300 g (with preamp microphone)
